LPV Low Profile Fan Powered Variable

Terminal Units

This low-profile terminal unit is designed to deliver warm plenum or return air to the primary air chamber and work noiselessly at the same time. The LPV features integral fan chamber mounted on the side (in parallel) to the primary air stream.

The patented Flo-Cross Sensor features 24-point upstream and downstream sensing with center averaging chambers and exclusive amplification wings (Patent # 4,453,419)
The fan is designed to run intermittently during occupied hours or during off-hours when only heating is required
The round damper blade is constructed of elastomeric gasket sandwiched between two heavy-gauge galvanized steel plates, resulting in low air leakage

LPV Low Profile Fan Powered Variable

Product Application

Are you equipped with the right system to control the air distribution within your facility? Our model LPV features a terminal fan designed to operate intermittently when only heating is required. Since the terminal fan does not run continuously, less energy is used. This makes it an energy-efficient solution that is ideal for reheat applications. It is also lined with dual-density fiberglass insulation to provide sound absorption and thermal resistance.

Features

Two casing sizes allow a total flow range of 200 to 1600 CFM
Listed by ETL for safety in accordance with standard UL 1995
Industry-standard round and rectangular inlet collars sized to accept either flexible or rigid ducts
Single-speed, 60 Hz motor (120, 208, 240, and 277 Volt) with SCR motor control

ARI-certified performance data
Heavy-duty 20-gauge casing construction
Fiberglass insulation meets NFPA 90 and UL 181 standards for erosion and safety
Large access panel for complete access to the fan and internal chamber of the unit
