FPP Fan Powered Parallel

Terminal Units

The basic operating principle of the FPP is that as the space cooling load is satisfied and the primary damper begins to close, the volume of primary air to the space is reduced. It offers a large access panel for you to get complete access to the fan and the internal chamber of unit.

The unit has a Flo-Cross airflow sensor at primary inlet
Features a primary inlet and damper, a fan mounted at the discharge of the unit and an induction port in the wall of the casing
The FPP is lined with insulation to provide sound absorption and thermal resistance

FPP Fan Powered Parallel

Product Application

Parallel terminal units are a vital component in your building’s HVAC system. They save energy and provide top-notch thermal comfort. They are fan-powered, which turn on only during heating mode drawing warmer plenum air, and work as a single-duct terminal unit in cooling modes. Operating at a low airflow rate, parallel fan-powered terminals are quieter than your average fan boxes. They can be used in a wide range of building applications, but are most effective in areas that have distinct heating requirements—particularly perimeter areas or spaces where the cooling loads can fluctuate.

Features

Fan airflow range of 60 through 3700 CFM with 6 different casing sizes
Industry-standard round inlet collars sized to accept either flexible or rigid duct
Integral backdraft damper
Optional auxiliary heat includes Hot Water and Electric heating coils (Solid State Relay heat is available)
List by ETL for safety in accordance with UL 1995

22-gauge casing construction (20-gauge optional)
Two-piece damper shaft utilizes Delrin self-lubricating bearings. Shaft end incorporates a damper position indicator
Single-speed, 60 Hz motor suitable for motor voltages of 120, 208, 240 and 277; includes standard motor SCR speed controller
Included in the AHRI Certified Performance program
